Setting up a user login system

Scout currently supports 4 types of login systems: - keycloak authentication via OpenID Connect - Google authentication via OpenID Connect - LDAP authentication - Simple authentication using userid

Login systems are mutually exclusive so when you choose a system, it will become be the only way all users will have access to the Scout app.

Keycloak OpenID Connect Login System

If your organization uses Keycloak as a login provider, Scout can be configured to authenticate users (who are already registered in the Scout database) using Keycloak in a few simple steps.

A small tutorial with basic settings (intended for testing only, not for production) is available on this page.

Assuming a Keycloak realm containing users is available, you can edit the Scout configuration file to enable this authentication method:

KEYCLOAK = dict(
    client_id="<name_of_client>",
    client_secret="secret", # available on Keycloak's admin console, under client credentials
    discovery_url="http://<url_to_keycloak_instance>/realms/<name_of_realm>/.well-known/openid-configuration",
    logout_url="http://<url_to_keycloak_instance>/realms/<name_of_realm>/protocol/openid-connect/logout",
)

Please note: For this setup to work, the Keycloak client must include the following parameter:

Valid redirect URIs: "http://<scout-uri>/authorized"

Users attempting to log in to Scout will be redirected to the Keycloak instance for authentication.

Google OpenID Connect login system

Scout supports Google account login via OpenID Connect. Before setting up the Google authentication system in Scout it is necessary to register the Scout application in the Google API console and obtain OAuth 2.0 credentials. A detailed guide on how to do this is available at this link.

In brief:

Create credentials for your demo app:

  • Go to this page: https://console.developers.google.com/apis/credentials?project=my-project-1507807614573&folder=&organizationId=

  • Click on credentials and choose the second option: OAuth Client ID image

  • Fill in this page with the following info: name: A name for your app Authorized JavaScript origins: https://your-scout-implementation-url:port Authorized redirect URIs: http://your-scout-implementation-url:port/authorized

  • Save these settings by clicking on the "Save" button

  • Note that a client_id and a client_secret are generated.

Edit the scout config file adding the following lines:

GOOGLE = dict(
    client_id="client_id",
    client_secret="client_secret",
    discovery_url="https://accounts.google.com/.well-known/openid-configuration"
)
  • Make sure that all users that should be allowed to log in in the app are already present in the Scout database with an id corresponding to a valid google email address.

The following command can be used to add a create a new user into the database: scout load user -i institute-id -u "User Name" -m user_emaill@email.com

Login using Lightweight Directory Access Protocol

Institutional directory services authentication via LDAP is supported by Scout.

LDAP authentication in Scout is achieved by using the flask-ldap3-login library.

Pre-requisites in order to authenticate users using LDAP:

  • An existing LDAP authentication server (external from Scout)
  • All users that should be logged in Scout using the LDAP should be previously saved into the scout database with an ID corresponding to a valid LDAP user.

The following command can be used to add a create a new user into the database: scout load user -id ldap_id (could be an email address) -i cust000 -u "User Name" -m useremail@email.com

Please note that the while the -id ldap_id option is not a mandatory parameter in the command used for adding users to the database, it is necessary for the LDAP login to successfully recognize the user in the system.

LDAP server instances are different from case to case. Some basic LDAP config options (with example values) that can be used on the in the Scout config file are the following:

LDAP Authentication Setup (Test Configuration)

For development and testing purposes, the login system can be connected to a public LDAP test server.

The following free LDAP server provided by Forum Systems can be used for testing: https://www.forumsys.com/2022/05/10/online-ldap-test-server/

This server provides a set of predefined users (e.g. einstein, tesla, newton) with a common password.

Configuration: To use the test LDAP server as a login system, in the scout config file, un-comment the provided test settings

# LDAP login Settings
LDAP_HOST = "ldap.forumsys.com"
LDAP_BIND_USER_DN = "cn=read-only-admin,dc=example,dc=com"
LDAP_BIND_USER_PASSWORD = "password"
LDAP_BASE_DN = "dc=example,dc=com"
LDAP_USER_DN = ""
LDAP_USER_RDN_ATTR = "uid"
LDAP_USER_LOGIN_ATTR = "uid"
LDAP_GROUP_DN = ""
LDAP_GROUP_OBJECT_FILTER = "(objectclass=*)"

Test users can be the following usernames: - einstein - newton - tesla - gauss - euler

All users share the password: password

In addition to LDAP authentication, a corresponding user must exist in Scout for the login to fully work. Create a matching Scout user with the same username using:

scout --demo load user -i cust000 -u "Isaac Newton" -m newton@email.com -id newton

This ensures that the LDAP identity can be mapped correctly to a Scout user record.

It should now be possible to log the new user in to Scout using username newton and password password

Considerations regarding the LDAP login in Scout.

Since the Scout software needs to define internal user objects, the LDAP login check against the server is only the first, authentication, step of the login process. The second, authorisation, step would be making sure that a user authenticated by a certain password exists also in the user collection of the Scout database. Because of this latter authorisation step, it is not strictly necessary to define a stringent set of rules (for instance which groups the user must belong to) for the LDAP login system, because a user from any group will be logged into Scout, as long as it's previously saved in the Scout database.

This means that if a user should be removed from the system, it is enough just to remove it from the Scout database.

Simple login with userid

Basic login with userid and password is the login system available whenever no advanced login system (either Google or LDAP) is specified in the Scout config file. To enable it, comment out or remove the LDAP and GOOGLE lines mentioned above from your config. It is an un-secure system which is not recommended to use. This is also the login system available in the demo instance of Scout.
